background image
Dual RPM-Based PWM Fan Controller with Hardware Thermal Shutdown
Datasheet
SMSC EMC2104
83
Revision 1.74 (05-08-08)
DATASHEET
6.44
Product ID Register
The Product ID Register contains a unique 8 bit word that identifies the product.
6.45
Manufacturer ID Register
The Manufacturer ID Register contains a 8 bit word that identifies SMSC.
6.46
Revision Register
The Revision Register contains a 8 bit word that identifies the die revision.
Table 6.62 Product ID Register
ADDR
R/W
REGISTER
B7
B6
B5
B4
B3
B2
B1
B0
DEFAULT
FDh
R
Product ID
Register
00
0
1
1
1
0
1
1Dh
Table 6.63 Manufacturer ID Register
ADDR
R/W
REGISTER
B7
B6
B5
B4
B3
B2
B1
B0
DEFAULT
FEh
R
Manufacturer ID
0
1
0
1
1
1
0
1
5Dh
Table 6.64 Revision Register
ADDR
R/W
REGISTER
B7
B6
B5
B4
B3
B2
B1
B0
DEFAULT
FFh
R
Revision
0
0
0
0
0
0
1
0
02h
