Dual RPM-Based PWM Fan Controller with Hardware Thermal Shutdown

Datasheet

Revision 1.74 (05-08-08)

SMSC EMC2104

DATASHEET

Bit 5 - NOKICKx - Determines if the Spin Up Routine will drive the fan to 100% duty cycle for 1/4 of

the programmed spin up time before driving it at the programmed level.

‘0’ (default) - The Spin Up Routine will drive the fan driver to 100% for 1/4 of the programmed spin

up time before reverting to the programmed spin level.

‘1’ - The Spin Up Routine will not drive the fan driver to 100%. It will set the drive at the

programmed spin level for the entire duration of the programmed spin up time.

Bits 4 - 2 - SPIN_LVL[2:0] - Determines the final drive level that is used by the Spin Up Routine as

shown in Table 6.39.

Bit 1 -0 - SPINUP_TIME[1:0] - determines the maximum Spin Time that the Spin Up Routine will run

for (see Section 6.9). If a valid tachometer measurement is not detected before the Spin Time has

elapsed, then an interrupt will be generated. When the RPM based Fan Speed Control Algorithm is

active, the fan driver will attempt to re-start the fan immediately after the end of the last spin up attempt.

The Spin Time is set as shown in Table 6.40.

Table 6.38 DRIVE_FAIL_CNT[1:0] Bit Decode

DRIVE_FAIL_CNT[1:0]

NUMBER OF UPDATE PERIODS

Disabled - the Drive Fail detection circuitry is

disabled (default)

16 - the Drive Fail detection circuitry will count for 16

update periods

32 - the Drive Fail detection circuitry will count for 32

update periods

64 - the Drive Fail detection circuitry will count for 64

update periods

Table 6.39 Spin Level

SPIN_LVL[2:0]

SPIN UP DRIVE LEVEL

30%

35%

40%

45%

50%

55%

60% (default)

65%
