3.0 System Wake-Up Control (SWC) (Continued)
95
www.national.com
3.4.9
Wake-Up Events Routing to IRQ Enable Register 0 (WK_IRQEN0)
This register is set to 00h on power-up of VPP or software reset. It controls the routing of detected wake-up events to the
assigned SWC interrupt request (IRQ) channel. Detected wake-up events that are enabled activate the assigned IRQ chan-
nel regardless of the value of the WK_EN0 register.
Location:
Bank 2, Offset 15h
Type:
R/W
Bit
76543210
Name
Reserved
Software
Event to
IRQ Enable
Reserved
CEIR
Event to
IRQ Enable
Mouse
Event to
IRQ Enable
KBD
Event to
IRQ Enable
RI2
Event to
IRQ Enable
RI1
Event to
IRQ Enable
Reset
00000000
Bit
Description
7
Reserved
6
Software Event to IRQ Enable
0: Disabled (default)
1: Enabled
5
Reserved
4
CEIR Event to IRQ Enable
0: Disabled (default)
1: Enabled
3
Mouse Event to IRQ Enable
0: Disabled (default)
1: Enabled
2
KBD Event to IRQ Enable
0: Disabled (default)
1: Enabled.
1
RI2 Event to IRQ Enable
0: Disabled (default)
1: Enabled
0
RI1 Event to IRQ Enable
0: Disabled (default)
1: Enabled
