 21 / 80 page
background image
19
D
C
B
E
L
A
H
K
L
TERMINATION ASSEMBLIES
“E” Open Wire Seal, “E” (SR) Strain Relief
“P” Potting Boot 75 degrees
PT08E-XX-XXX
SP08E-XX-XXX
PT08E-XX-XXX (SR)
SP08E-XX-XXX (SR)
PT08P-XX-XXX
SP08P-XX-XXX
To complete part number see how to order on page 27.
All lockwire holes are .044 Dia. Min.
All dimensions for reference only.
Shell
Size
Plug Front View
Plug Side View
G
Dia.
Max.
Class “E”, “E” (SR)
Class “P”
B
±.031
C
+.010
–.025
D
±.062
E
+.047
–.025
L
±.057
A
±.025
H
±.015
K
±.015
L
Max.
8
.796
.655
.169
.941
.339
1.786
.469
.312
.438
1.656
10
.921
.749
.170
1.191
.393
1.880
.547
.438
.562
1.781
12
1.046
.812
.264
1.191
.450
1.965
.625
.516
.688
1.843
14
1.171
.905
.310
1.254
.519
2.113
.734
.625
.781
1.953
16
1.297
1.030
.330
1.316
.583
2.315
.750
.656
.890
2.000
18
1.422
1.015
.444
1.562
.621
2.423
.781
.703
1.000
2.046
20
1.562
1.077
.510
1.625
.683
2.695
.859
.766
1.125
2.218
22
1.672
1.139
.515
1.719
.739
2.742
.906
.812
1.234
2.265
24
1.797
1.265
.656
1.751
.797
2.980
1.169
.918
1.374
2.624
PT08 E
SP08 E
90 degree plug
G
