Section 6 Bus Controller (BSC)
Rev.1.00 Jun. 07, 2006 Page 225 of 1102
REJ09B0294-0100
6.9.9
Extension of Chip Select (
CS) Assertion Period
In the address/data multiplexed interface, the extension cycles can be inserted before and after the
bus cycle. For details, see section 6.6.6, Extension of Chip Select (
CS) Assertion Period.
Figure 6.35 shows an example of the chip select (
CS) assertion period extension timing.
T
ma1
T
ma2
T
2
T
t
T
1
T
h
B
φ
Address bus
D15 to D0
D15 to D0
Address cycle
Bus cycle
Data cycle
CSn
LHWR
LLWR
AH
RD
DACK
BS
RD/
WR
Note: n = 3 to 7
Address
Read data
Address
Write data
Read
Write
Figure 6.35 Chip Select (
CS) Assertion Period Extension Timing in Data Cycle
