CS7654

Subcarrier Amplitude Register at SA 0x00h

Address

×10

SC_AMP

Read/Write

Default Value = 1Ch

Subcarrier Synthesis Register at SA 0x00h

Address

×11

SC_SYNTH0

Read/Write

Default Value = 3Eh

×12

SC_SYNTH1

F8h

×13

SC_SYNTH2

E0h

×14

SC_SYNTH3

43h

Hue LSB Adjust Register at SA 0x00h

Address

×15

HUE_LSB

Read/Write

Default Value = 00h

Hue MSB Adjust Register at SA 0x00h

Address

×16

HUE_MSB

Read/Write

Default Value = 00h

Bit Number

654

Bit Name

BU AMP

Default

001

Bit

Mnemonic

Function

7:0

BU AMP

Color burst amplitude

Bits

Mnemonic

Function

SC_SYNTH0

7:0

CC 0

Subcarrier synthesis bits 7:0

SC_SYNTH1

7:0

CC 1

Subcarrier synthesis bits 15:8

SC_SYNTH2

7:0

CC 2

Subcarrier synthesis bits 23:16

SC_SYNTH3

7:0

CC 3

Subcarrier synthesis bits 31:24

Bit Number

765

432

Bit Name

HUE LSB

Default

000

Bit

Mnemonic

Function

7:0

HUE LSB

8 LSBs for hue phase shift

Bit Number

654

Bit Name

RESERVED

MSB

Default

000

Bit

Mnemonic

Function

7:2

reserved

1:0

HUE MSB

2 MSBs for hue phase shift
