Push Buttons and Switches

2-8

ADSP-BF506F EZ-KIT Lite Evaluation System Manual

UART Setup Switch (SW1)

The UART setup switch (SW1) configures the UART0 signals between the

DCE connector (J1) and processor. Table 2-5 shows the switch settings.

Boot Mode Select Switch (SW2)

The boot mode select switch (SW2) determines the boot mode of the pro-

cessor. Table 2-5 shows the available boot mode settings. By default, the

ADSP-BF506F processor boots from SPI flash memory.

Table 2-4. UART Setup Switch (SW1)

SW1 Position

Function

1 and 3

Enable flow control

Disconnects the UART_RX signal from the processor;

the UART_RX signal can be used for another function

Connects the RTS and CTS signals together

Allows the host to reset the EZ-KIT Lite via the CTS signal

6 and 7

Selects the source for the CTS signal

Loops the TX and RX signals together for testing

Table 2-5. Boot Mode Select Switch (SW2)

SW2 Position

Processor Boot Mode

Idle—no boot

Boots from stacked parallel flash in asynchronous mode

Boots from stacked parallel flash in synchronous mode

Boots through SPI0 master from SPI memory

Boots through SPI0 slave from host device

Boots through PPI from host
