5 / 17 page  Smart Card Interface _______________________________________________________________________________________ 5 RECOMMENDED DC OPERATING CONDITIONS (continued) (VDD = +3.3V, VDDA = +5.0V, TA = +25°C, unless otherwise noted.) (Note 1) PARAMETER SYMBOL CONDITIONS MIN TYP MAX UNITS I/OIN, AUX1IN, AUX2IN PINS Output Low Voltage VOL IOL = 1mA 0 0.3 V No Load 0.9 x VDD VDD + 0.1 Output High Voltage VOH IOH < -40μA 0.75 x VDD VDD + 0.1 V Output Rise/Fall Time tOT CL = 30pF, 10% to 90% 0.1 μs Input Low Voltage VIL -0.3 0.3 x VDD V Input High Voltage VIH 0.7 x VDD VDD + 0.3 V Input Low Current IIL_IO VIL = 0V 700 μA Input High Current IIH_IO VIH = VDD 10 μA Input Rise/Fall Time tIT VIL to VIH 1.2 μs Integrated Pullup Resistor RPU Pullup to VDD 9 11 13 k Current When Pullup Active IPU CL = 30pF, VOH = 0.9 x VDD -1 mA CONTROL PINS (CLKDIV1, CLKDIV2, CMDVCC, RSTIN, 5V/3V, 1_8V) Input Low Voltage VIL -0.3 0.3 x VDD V Input High Voltage VIH 0.7 x VDD VDD + 0.3 V Input Low Current IIL_IO 0 < VIL < VDD 5 μA Input High Current IIH_IO 0 < VIH < VDD 5 μA INTERRUPT OUTPUT PIN (OFF) Output Low Voltage VOL IOL = 2mA 0 0.3 V Output High Voltage VOH IOH = -15μA 0.75 x VDD V Integrated Pullup Resistor RPU Pullup to VDD 16 20 24 k PRES, PRES PINS Input Low Voltage VIL_PRES 0.3 x VDD V Input High Voltage VIH_PRES 0.7 x VDD V Input Low Current IIL_PRES VIL_PRES = 0V 40 μA Input High Current IIH_PRES VIH_PRES = VDD 40 μA |
|
|
