Section 10 16-Bit Timer Pulse Unit (TPU)

Rev.1.00 Jun. 07, 2006 Page 528 of 1102

REJ09B0294-0100

10.3.4

Timer Interrupt Enable Register (TIER)

TIER controls enabling or disabling of interrupt requests for each channel. The TPU has six TIER

registers, one for each channel.

Bit

Bit Name

Initial Value

R/W

TTGE

R/W



TCIEU

R/W

TCIEV

R/W

TGIED

R/W

TGIEC

R/W

TGIEB

R/W

TGIEA

R/W

Bit

Bit Name

Initial

value

R/W

Description

TTGE

R/W

A/D Conversion Start Request Enable

Enables/disables generation of A/D conversion start

requests by TGRA input capture/compare match.

0: A/D conversion start request generation disabled

1: A/D conversion start request generation enabled



Reserved

This is a read-only bit and cannot be modified.

TCIEU

R/W

Underflow Interrupt Enable

Enables/disables interrupt requests (TCIU) by the TCFU

flag when the TCFU flag in TSR is set to 1 in channels 1,

2, 4, and 5.

In channels 0 and 3, bit 5 is reserved. It is always read as

0 and cannot be modified.

0: Interrupt requests (TCIU) by TCFU disabled

1: Interrupt requests (TCIU) by TCFU enabled

TCIEV

R/W

Overflow Interrupt Enable

Enables/disables interrupt requests (TCIV) by the TCFV

flag when the TCFV flag in TSR is set to 1.

0: Interrupt requests (TCIV) by TCFV disabled

1: Interrupt requests (TCIV) by TCFV enabled
