STLS2F01

Electrical characteristics

37/48

Electrical characteristics

6.1

Absolute maximum rating

Stresses above the absolute maximum ratings listed in Table 13 may cause permanent

damage to the device. These are stress ratings only and functional operation of the device

at these conditions is not implied. Exposure to maximum rating conditions for extended

period may affect device reliability.

6.2

Recommended operation environment

Table 13.

Absolute maximum rating.

Parameter

Description

Min

Max

Unit

vdd

CPU core voltage

1.2

1.3

vdde1v8

DDR2 voltage

1.7

1.9

vdde3v3

IO voltage

3.0

3.6

DDR2_VREF

DDR2 voltage reference

0.83

0.97

pll_vdd_1

1.0V PLL1 digital voltage

0.9

1.3

pll_vdd_0

1.0V PLL0 digital voltage

0.9

1.3

pllio_vdde1v8

1.8V PLL IO voltage

1.7

1.9

pll_vdde1v8_1

1.8V PLL1 analog voltage

1.7

1.9

Pll_vdde1v8_0

1.8V PLL0 analog voltage

1.7

1.9

pllio_vdd

1.2V PLL IO voltage

0.9

1.3

Storage Temperature

°C

Table 14.

Recommended operating temperature, voltage supply and frequency

Parameter

Description

Min

Typ

Max

Unit

Operating Temperature

°C

vdd

CPU core voltage

1.25

Vdde1v8

DDR2 voltage

1.8

vdde3v3

I/O voltage

3.3

DDR2_VREF

DDR2 voltage reference

0.9

pll_vdd_1

1.0V PLL1 digital voltage

1.2

pll_vdd_0

1.0V PLL0 digital voltage

1.2

pllio_vdde1v8

1.8V PLL I/O voltage

1.8

pll_vdde1v8_1

1.8V PLL1 analog voltage

1.8

Pll_vdde1v8_0

1.8V PLL0 analog voltage

1.8

pllio_vdd

1.2V PLL I/O voltage

1.2
