E5CC-RX2DBM-000 datasheet(29/138 Pages) OMRON

29 / 138 page

E5CC/E5CC-B/E5CC-U

USB-Serial Conversion Cable

Windows is a registered trademark of Microsoft Corporation in the

United States and or other countries.

*1. CX-Thermo version 4.65 or higher runs on Windows 10.

*2. Use a high-power port for the USB port.

*3. CX-Thermo version 4.67 or higher is required for the E5CC-B

linear current output type.

Note: A driver must be installed on the computer. Refer to the Instruction

Manual

included with the Cable for the installation procedure.

Communications Specifications

* The baud rate, data bit length, stop bit length, and vertical parity can

be individually set using the Communications Setting Level.

Communications Functions

MELSEC is a registered trademark of Mitsubishi Electric Corporation.

KEYENCE is a registered trademark of Keyence Corporation.

*1. A Temperature Controller with version 1.1 or higher is required.

A Temperature Controller with version 2.1 or higher is required for

the FX Series or the KV Series.

*2. Both the programless communications and the component

communications support the copying.

Current Transformer (Order Separately) Ratings

Heater Burnout Alarms and SSR Failure Alarms

*1. For heater burnout alarms, the heater current will be measured

when the control output is ON, and the output will turn ON if the

heater current is lower than the set value (i.e., heater burnout

detection current value).

*2. For SSR failure alarms, the heater current will be measured when the

control output is OFF, and the output will turn ON if the heater current

is higher than the set value (i.e., SSR failure detection current value).

*3. The value is 30 ms for a control period of 0.1 s or 0.2 s.

*4. The value is 35 ms for a control period of 0.1 s or 0.2 s.

Electrical Life Expectancy Curve for

Control Output Relays (Reference Values)

Applicable OS

Windows XP/Vista/7/8/10

Applicable software

CX-Thermo version 4.5 or higher

(Version 4.61 or higher is required for the

E5CC-U, Version 4.65 or higher is required

for the E5CC-B

*3.)

Applicable models

@C-T Series, E5@C Series, and E5CB Series

USB interface standard Conforms to USB Specification 2.0.

DTE speed

38400 bps

Connector

specifications

Computer: USB (type A plug)

Digital Temperature Controller:

Special serial connector

Power supply

Bus power (Supplied from USB host controller.)

Power supply voltage 5 VDC

Current consumption 450 mA max.

Output voltage

4.7

±0.2 VDC

(Supplied from USB-Serial Conversion Cable

to the Digital Temperature Controller.)

Output current

250 mA max.

(Supplied from USB-Serial Conversion Cable

to the Digital Temperature Controller.)

Ambient operating

temperature

0 to 55°C (with no condensation or icing)

Ambient operating humidity 10% to 80%

Storage temperature -20 to 60°C (with no condensation or icing)

Storage humidity

10% to 80%

Altitude

2,000 m max.

Weight

Approx. 120 g

Transmission line

connection method

RS-485: Multidrop

Communications

RS-485 (two-wire, half duplex)

Synchronization method Start-stop synchronization

Protocol

CompoWay/F, or Modbus

Baud rate

9600, 19200, 38400, or 57600 bps

Transmission code

ASCII

Data bit length

7 or 8 bits

Stop bit length

1 or 2 bits

Error detection

Vertical parity (none, even, odd)

Block check character (BCC) with

CompoWay/F or CRC-16 Modbus

Flow control

None

Interface

RS-485

Retry function

None

Communications buffer 217 bytes

Communications

response wait time

0 to 99 ms

Default: 20 ms

Programless

communications

You can use the memory in the PLC to read and write

@C parameters, start and stop operation, etc. The

@C automatically performs communications with

PLCs. No communications programming is required.

Number of connected Digital Temperature

Controllers: 32 max. (Up to 16 for the FX Series)

Applicable PLCs

OMRON PLCs

CS Series, CJ Series, CP Series,

NJ Series, or NX1P

Mitsubishi Electric PLCs

MELSEC Q Series, L Series, FX3 Series,

or iQ-R Series

KEYENCE PLCs

KEYENCE KV Series

Component

Communications

When Digital Temperature Controllers are

connected, set points and RUN/STOP

commands can be sent from the Digital

Temperature Controller that is set as the

master to the Digital Temperature

Controllers that are set as slaves.

Slope and offsets can be set for the set point.

Number of connected Digital Temperature

Controllers: 32 max. (including master)

Copying

When Digital Temperature Controllers are

connected, the parameters can be copied

from the Digital Temperature Controller that is

set as the master to the Digital Temperature

Controllers that are set as slaves.

E54-CT1

E54-CT3

E54-CT1L

E54-CT3L

Dielectric strength 1,000 VAC for 1 min

1,500 VAC for 1 min

Vibration resistance

50 Hz, 98 m/s2

Weight

E54-CT1: Approx. 11.5 g

E54-CT3: Approx. 50 g

E54-CT1L: Approx. 14 g

E54-CT3L: Approx. 57 g

Accessories

E54-CT3 Only

Armatures (2)

Plugs (2)

None

CT input (for heater

current detection)

Models with detection for single-phase

heaters: One input

Models with detection for singlephase or

three-phase heaters: Two inputs

Maximum heater current 50 A AC

Input current

indication accuracy

±5% FS ±1 digit max.

Heater burnout alarm

setting range

0.1 to 49.9 A (in units of 0.1 A)

Minimum detection ON time: 100 ms

SSR failure alarm

setting range

0.1 to 49.9 A (in units of 0.1 A)

Minimum detection OFF time: 100 ms

500

300

100

12345

Switching current (A)

E5CC/E5CC-B

250 VAC, 30 VDC

(resistive load)

cosφ = 1
