E5CD/E5ED

3. Recommended Ferrules and Crimp Tools

Recommended wires (Stranded wire/Solid wire)

Recommended ferrules

*1. Make sure that the outer diameter of the wire coating is smaller than the

inner diameter of the insulation sleeve of the recommended ferrule.

*2. Make sure that the ferrule processing dimensions conform to the following

figures.

Recommended Flat-blade Screwdriver

Use a flat-blade screwdriver to connect and remove wires.

Use the following flat-blade screwdriver.

The following table shows manufacturers and models as of 2015/Dec

* OMRON's exclusive purchase model XW4Z-00B is available to

order as SZF 0-0,4

✕2,5 (manufactured by Phoenix Contact).

Three-year Guarantee

Period of Guarantee

The guarantee period of the Unit is three years starting from the date

the Unit is shipped from the factory.

Scope of Guarantee

The Unit is guaranteed under the following operating conditions.

1. Average Operating Temperature

(see note):

−10°C to 50°C

2. Mounting Method: Standard mounting

(Mounted to panel or DIN Track.)

Note: Average Operating Temperature

Refer to the process temperature of the Unit mounted to a

control panel and connected to peripheral devices on condition

that the Unit is in stable operation, sensor input type K is

selected for the Unit, the positive and negative thermocouple

input terminals of the Unit are short-circuited, and the ambient

temperature is stable.

Should the Unit malfunction during the guarantee period, OMRON

shall repair the Unit or replace any parts of the Unit at the expense of

OMRON

Recommended wire

Stripping length

(Ferrules not used)

0.25-1.5 mm2/AWG24-16

8 mm

Applicable

wire

Ferrule

Conductor

length

(mm)

Wire

Stripping

length

(mm)

(Ferrules

used)

Recommended ferrules

(mm2)

(AWG)

Phoenix Contact

product

Weidmuller

product

Wago

product

0.25

10 AI 0,25-8

H0.25/12 216-301

12 AI 0,25-10

---

0.34

10 AI 0,34-8

H0.34/12 216-302

12 AI 0,34-10

---

0.5

10 AI 0,5-8

H0.5/14

216-201

12 AI 0,5-10

H0.5/16

216-241

0.75

10 AI 0,75-8

H0.75/14 216-202

12 AI 0,75-10

H0.75/16 216-242

1/1.25 18/17

10 AI 1-8

H1.0/14

216-203

12 AI 1-10

H1.0/16

216-243

1.25/1.5 17/16

10 AI 1,5-8

H1.5/14

216-204

12 AI 1,5-10

H1.5/16

216-244

Recommended crimp tool

CRIMPFOX6

CRIMPFOX6T-F

CRIMPFOX10S

PZ6 roto

Variocrimp4

1.9 mm max.

2.6 mm max.

8 to 10 mm

Model

Manufacturer

ESD 0,40

✕2,5

Wera

SZS 0,4

✕2,5

SZF 0-0,4

✕2,5 *

Phoenix Contact

0.4

✕2.5✕75 302

Wiha

AEF.2,5

✕75

Facom

210-719

Wago

SDI 0.4

✕2.5✕75

Weidmuller

Front

Side

0.4 mm

2.5 mm dia.

2.5 mm

Top

Bottom

Example: Mounted to Panel

Example: Mounted to DIN Track

Top

Bottom
