E5CD/E5CD-B

Accessories (Order Separately)

(2110)

250

263

1510

LED (SD)

LED (PWR)

LED (RD)

USB connector

(type A plug)

Serial connector

USB-Serial Conversion Cable

E58-CIFQ2

48.8

9.1

Terminal Covers (Cannot be used on a Push-In Plus terminal block type)

E53-COV17

44.8

3.8

Terminal Cover

(E53-COV23)

Terminal Covers (Cannot be used on a Push-In Plus terminal block type)

E53-COV23 (Three Covers provided.)

The Terminal Covers are provided with the Digital Temperature

Controller.

Order the Terminal Cover separately if it becomes lost or damaged.

Waterproof Packing

Y92S-P8 (for DIN 48

× 48)

The Waterproof Packing is provided with the Digital Temperature Controller.

Order the Waterproof Packing separately if it becomes lost or damaged.

The Waterproof Packing can be used to achieve an IP66 degree of protection.

(Deterioration, shrinking, or hardening of the waterproof packing may occur

depending on the operating environment. Therefore, periodic replacement is

recommended to ensure the level of waterproofing specified in IP66. The time for

periodic replacement depends on the operating environment.

Be sure to confirm this point at your site. Consider three years as rough standard.)
