I-76

Digital Controller

E5CK

Level 2 Mode

lcl

m

s p r u

0

0

0.0

0.0

105.0

-5.0

0.0

0

i n f

0.02

0.02

0.0

s p r t

l b a

m U - s

o r l

a l h 1

i n s h

r - l

m U - e

o l - h

o l - l

a l h 2

0.0

i n s l

Remote/Local

Used for the communications function.

SP Ramp Time Unit

SP Ramp Set Value

LBA Detection Time

Available only when the LBA (loop break alarm) function of the Controller is selected.

MV at Stop

MV at PV Error

MV Upper Limit

MV Lower Limit

MV Change Rate Limit

Input Digital Filter

Alarm 1 Hysteresis

Available only when the Controller has an alarm output.

Alarm 2 Hysteresis

Available only when the Controller has an alarm output.

Input Shift Upper Limit

Input Shift Lower Limit

Available if the input type connected to the Controller is a thermocouple or platinum resistance

thermometer.

Available if the input type connected to the Controller is a thermocouple or platinum resistance

thermometer.
