12 / 84 page ![]() CC2500 PRELIMINARY Data Sheet (Rev.1.2) SWRS040A Page 12 of 83 4.7 Analog Temperature Sensor The characteristics of the analog temperature sensor are listed in Table 10 below. Note that it is necessary to write 0xBF to the PTEST register to use the analog temperature sensor in the IDLE state. Parameter Min Typ Max Unit Condition/Note Output voltage at –40 °C 0.660 V Output voltage at 0 °C 0.755 V Output voltage at +40 °C 0.859 V Output voltage at +80 °C 0.958 V Temperature coefficient 2.54 mV/ °C Fitted from –20 °C to +80°C Error in calculated temperature, calibrated -2 * 0 2 * °C From –20 °C to +80°C when using 2.54 mV / °C, after 1-point calibration at room temperature * The indicated minimum and maximum error with 1- point calibration is based on simulated values for typical process parameters Current consumption increase when enabled 0.3 mA Table 10: Analog temperature sensor parameters 4.8 DC Characteristics Tc = 25 °C if nothing else stated. Digital Inputs/Outputs Min Max Unit Condition Logic "0" input voltage 0 0.7 V Logic "1" input voltage VDD-0.7 VDD V Logic "0" output voltage 0 0.5 V For up to 4 mA output current Logic "1" output voltage VDD-0.3 VDD V For up to 4 mA output current Logic "0" input current NA –50 nA Input equals 0 V Logic "1" input current NA 50 nA Input equals VDD Table 11: DC characteristics 4.9 Power-On Reset When the power supply complies with the requirements in Table 12 below, proper Power-On- Reset functionality is guaranteed. Otherwise, the chip should be assumed to have unknown state until transmitting an SRES strobe over the SPI interface. See Section 19.1 on page 36 for further details. Parameter Min Typ Max Unit Condition/Note Power ramp-up time 5 ms From 0 V until reaching 1.8 V Power off time 1 ms Minimum time between power-on and power-off. Table 12: Power-on reset requirements |
|
