WM8775EDSSLASHR datasheet(21/36 Pages) WOLFSON

21 / 36 page

Product Preview

WM8775

PP Rev 1.8, June 2004

ADC OVERSAMPLING RATE SELECT

For ADC operation at 96kHz it is recommended that the user set the ADCOSR bit. This changes the

ADC signal processing oversample rate to 64fs.

BIT

LABEL

DEFAULT

DESCRIPTION

R12(0Ch)

0001100

ADC Oversampling Rate

ADCOSR

ADC oversampling rate select

0: 128x oversampling

1: 64x oversampling

POWERDOWN MODE AND ADC DISABLE

Setting the PDWN register bit immediately powers down the WM8775, including the references,

overriding all other powerdown control bits. All trace of the previous input samples is removed, but all

control register settings are preserved. When PDWN is cleared, the digital filters will be re-initialised.

It is recommended that the 4-channel input mux and buffer, and ADC are powered down before

setting PDWN.

The ADC may also be powered down by setting the ADCPD disable bit. Setting ADCPD will disable

the ADC and select a low power mode. The ADC digital filters will be reset and will reinitialise when

ADCPD is reset.

BIT

LABEL

DEFAULT

DESCRIPTION

PDWN

Power Down Mode Select:

0 : Normal Mode

1: Power Down Mode

ADCPD

ADC Disable:

0 : Normal Mode

1: Power Down Mode

R13(0Dh)

0001101

Powerdown Control

AINPD

Analogue Input Disable:

0 : Normal Mode

1 : Power Down Mode

ADC GAIN CONTROL

The ADC has an analogue input PGA and digital gain control for each stereo channel. Both the

analogue and digital gains are adjusted by the same register, LAG for the left and RAG for the right.

The analogue PGA has a range of +24dB to -21dB in 0.5dB steps. The digital gain control allows

further attenuation (after the ADC) from -21.5dB to -103dB in 0.5dB steps. Table 11 shows how the

LAG/RAG[7:0]

ATTENUATION

LEVEL

ANALOGUE PGA

DIGITAL

ATTENTUATION

00(hex)

∞ dB (mute)

-21dB

Digital mute

01(hex)

-103dB

-21dB

-82dB

A4(hex)

-21.5dB

-21dB

-0.5dB

A5(hex)

-21dB

0dB

CF(hex)

0dB

FE(hex)

+23.5dB

0dB

FF(hex)

+24dB

0dB

Table 11 Analogue and Digital Gain Mapping for ADC

Left and right inputs may also be independently muted. The LRBOTH control bit allows the user to

write the same attenuation value to both left and right volume control registers, saving on software

writes. The ADC volume and mute also applies to the bypass signal path.
