EM346
Rev 1.0
127
48
OSCA
I/O
24 MHz crystal oscillator or external clock input.
(An external clock input should only be used for test and debug purposes.
If used in this manner, the external clock input should be a 1.8 V, 50% duty
cycle, square wave.)
49
GND
Ground
Ground supply pad in the bottom center of the package forms Pin 49. See
the various Ember
EM35x Reference Design documentation for PCB con-
siderations.
Table 17.1. EM346 Pin Descriptions (Continued)
Pin #
Signal
Direction
Description
