ADRF6518

Preliminary Technical Data

Rev. PrA | Page 6 of 36

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Supply Voltages, VPS, VPSD

3.45 V

ENBL, LE, CLK, DATA, SDO

VPSD + 0.5 V

INP1, INM1, INP2, INM2, VICM

VPS + 0.5 V

OPP1, OPM1, OPP2, OPM2, VOCM

VPS + 0.5 V

OFS1, OFS2, VPK, RAVG

VPS + 0.5 V

VGN1, VGN2, VGN3

VPS + 0.5 V

Internal Power Dissipation

1.25 W

θJA (Exposed Pad Soldered to Board)

37.4°C/W

Maximum Junction Temperature

150°C

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Lead Temperature (Soldering 60 sec)

300°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

ESD CAUTION
