P9415-R Datasheet

May 4, 2021

Table 16. Firmware Revision Minor (0x09)

Address

and Bit

R/W

Default

Value

Function and Description

0x09 [7:0]

Minor

0x01

Firmware minor revision

Table 17. Firmware Revision Beta (0x0A)

Address

and Bit

R/W

Default

Value

Function and Description

0x0a [7:0]

beta

0x00

Firmware revision beta

Table 18. Date Register (0x0C)

Address

and Bit

R/W

Default

Value

Function and Description

0x0c [96:0]

Date

12-byte string initialized with FW compile data code. The format of the string is:

“Mmm DD YYYY”, where Mmm is a three letter Month code, followed by the date in

the month and the year. The string is terminated with 0x00.

Table 19. Time Register, (0x18)

Address

and Bit

R/W

Default

Value

Function and Description

0x18 [64:0]

Time

8-byte string initialized with FW compile time code. The format of the string is:

“HH:MM:SS”. The string is not zero terminated.

Table 20. Part Number Register (0x20)

Address

and Bit

R/W

Default

Value

Function and Description

0x20 [32:0]

Part Number

0x520000

Part number.

Note: The bit definition in Rx mode and Tx mode is different.
