4 / 15 page ![]() ADRF5250 Data Sheet Rev. 0 | Page 4 of 15 Parameter Symbol Test Conditions/Comments Min Typ Max Unit RECOMMENDED OPERATING CONDITIONS Supply Voltage Positive VDD 3.0 5.25 V Negative VSS −3.45 −3.15 V Digital Control Voltage V1, V2, V3 0 VDD V Maximum RF Input Power1 PIN TCASE = 105°C Through path (VDD = 3.3 V to 5 V) 30 dBm Terminated path 24 dBm Hot switching 24 dBm TCASE = 85°C Through path (VDD = 3.3 V to 5 V) 33 dBm Terminated path 27 dBm Hot switching 27 dBm Case Temperature TCASE −40 +105 °C 1 Exposure to levels between the recommended operating conditions and the absolute maximum rating conditions for extended period may affect device reliability. |
|
|
