MB96340 Series

Document Number: 002-04579 Rev. *A

Page 102 of 109

17. Package Dimension MB96(F)34x QFP 100P

100-pin plastic QFP

Lead pitch

0.65 mm

Package width

package length

14.00 mm

× 20.00 mm

Lead shape

Gullwing

Sealing method

Plastic mold

Mounting height

3.35 mm MAX

Code

(Reference)

P-QFP100-14

×20-0.65

100-pin plastic QFP

(FPT-100P-M22)

2006-2008 FUJITSU MICROELECTRONICS LIMITED F100033S-c-1-2

100

20.00±0.20(.787±.008)

23.90±0.40(.941±.016)

14.00±0.20

(.551±.008)

17.90±0.40

(.705±.016)

INDEX

0.65(.026)

0.32±0.05

(.013±.002)

0.13(.005)

"A"

0.17±0.06

(.007±.002)

0.10(.004)

Details of "A" part

(.035±.006)

0.88±0.15

(.031±.008)

0.80±0.20

0.25(.010)

3.00

+0.35

–0.20

+.014

–.008

.118

(Mounting height)

0.25±0.20

(.010±.008)

(Stand off)

0~8°

Dimensions in mm (inches).

Note: The values in parentheses are reference values.

Note 1) * : These dimensions do not include resin protrusion.

Note 2) Pins width and pins thickness include plating thickness.

Note 3) Pins width do not include tie bar cutting remainder.
