30 / 109 page  MB96340 Series Document Number: 002-04579 Rev. *A Page 30 of 109 0000C1H USART0 - Serial Control Register SCR0 R/W 0000C2H USART0 - TX Register TDR0 W 0000C2H USART0 - RX Register RDR0 R 0000C3H USART0 - Serial Status SSR0 R/W 0000C4H USART0 - Control/Com. Register ECCR0 R/W 0000C5H USART0 - Ext. Status Register ESCR0 R/W 0000C6H USART0 - Baud Rate Generator Register Low BGRL0 BGR0 R/W 0000C7H USART0 - Baud Rate Generator Register High BGRH0 R/W 0000C8H USART0 - Extended Serial Interrupt Register ESIR0 R/W 0000C9H Reserved - 0000CAH USART1 - Serial Mode Register SMR1 R/W 0000CBH USART1 - Serial Control Register SCR1 R/W 0000CCH USART1 - TX Register TDR1 W 0000CCH USART1 - RX Register RDR1 R 0000CDH USART1 - Serial Status SSR1 R/W 0000CEH USART1 - Control/Com. Register ECCR1 R/W 0000CFH USART1 - Ext. Status Register ESCR1 R/W 0000D0H USART1 - Baud Rate Generator Register Low BGRL1 BGR1 R/W 0000D1H USART1 - Baud Rate Generator Register High BGRH1 R/W 0000D2H USART1 - Extended Serial Interrupt Register ESIR1 R/W 0000D3H Reserved - 0000D4H USART2 - Serial Mode Register SMR2 R/W 0000D5H USART2 - Serial Control Register SCR2 R/W 0000D6H USART2 - TX Register TDR2 W 0000D6H USART2 - RX Register RDR2 R 0000D7H USART2 - Serial Status SSR2 R/W 0000D8H USART2 - Control/Com. Register ECCR2 R/W 0000D9H USART2 - Ext. Status Register ESCR2 R/W 0000DAH USART2 - Baud Rate Generator Register Low BGRL2 BGR2 R/W 0000DBH USART2 - Baud Rate Generator Register High BGRH2 R/W 0000DCH USART2 - Extended Serial Interrupt Register ESIR2 R/W 0000DDH Reserved - Table 4: I/O map MB96(F)34x Address Register Abbreviation 8-bit access Abbreviation 16-bit access Access |
|
