42 / 109 page  MB96340 Series Document Number: 002-04579 Rev. *A Page 42 of 109 00056DH PPG7 - Timer register R 00056EH PPG7 - Period setting register PCSR7 W 00056FH PPG7 - Period setting register W 000570H PPG7 - Duty cycle register PDUT7 W 000571H PPG7 - Duty cycle register W 000572H PPG7 - Control status register Low PCNL7 PCN7 R/W 000573H PPG7 - Control status register High PCNH7 R/W 000574H PPG11-PPG8 - General Control register 1 Low GCN1L2 GCN12 R/W 000575H PPG11-PPG8 - General Control register 1 High GCN1H2 R/W 000576H PPG11-PPG8 - General Control register 2 Low GCN2L2 GCN22 R/W 000577H PPG11-PPG8 - General Control register 2 High GCN2H2 R/W 000578H PPG8 - Timer register PTMR8 R 000579H PPG8 - Timer register R 00057AH PPG8 - Period setting register PCSR8 W 00057BH PPG8 - Period setting register W 00057CH PPG8 - Duty cycle register PDUT8 W 00057DH PPG8 - Duty cycle register W 00057EH PPG8 - Control status register Low PCNL8 PCN8 R/W 00057FH PPG8 - Control status register High PCNH8 R/W 000580H PPG9 - Timer register PTMR9 R 000581H PPG9 - Timer register R 000582H PPG9 - Period setting register PCSR9 W 000583H PPG9 - Period setting register W 000584H PPG9 - Duty cycle register PDUT9 W 000585H PPG9 - Duty cycle register W 000586H PPG9 - Control status register Low PCNL9 PCN9 R/W 000587H PPG9 - Control status register High PCNH9 R/W 000588H PPG10 - Timer register PTMR10 R 000589H PPG10 - Timer register R 00058AH PPG10 - Period setting register PCSR10 W 00058BH PPG10 - Period setting register W 00058CH PPG10 - Duty cycle register PDUT10 W Table 4: I/O map MB96(F)34x Address Register Abbreviation 8-bit access Abbreviation 16-bit access Access |
|
