STHDLS101A
Package mechanical data
Doc ID 15756 Rev 1
21/24
Figure 7.
Tape information for QFN48 (7 x 7 x 1 mm) - 0.5 mm pitch
Table 15.
Package mechanical data for QFN48 (7 x 7 x 1 mm) - 0.5 mm pitch
Symbol
Min
Typ
Max
Min
Typ
Max
A
0.80
0.90
1.00
0.80
0.85
1.00
A1
−
0.02
0.05
−
0.01
0.05
A2
−
0.65
1.00
−
0.65
−
A3
−
0.25
−−
0.20
−
b
0.18
0.23
0.30
0.18
0.23
0.30
D
6.85
7.00
7.15
6.90
7.00
7.10
D2
2.25
4.70
5.25
SEE EXPOSED PAD VARIATIONS
E
6.85
7.00
7.15
6.90
7.00
7.10
E2
2.25
4.70
5.25
SEE EXPOSED PAD VARIATIONS
e
0.45
0.50
0.55
0.45
0.50
0.55
L
0.30
0.40
0.50
0.30
0.40
0.50
ddd
−−
0.08
−−
0.08
