OutlineDimensions(Inch/mm)

Schematics

No. of Leads

.100 ± .005

2.54 ± 0.13

Pitch. Non-

Accumulative

.020 ± .004

0.51 ± 0.10

.012 ± .003

0.31 ± 0.08

Centered

on Package

.140 ± .020

3.56 ± 0.51

Max.

“L” Max.

Max.

12

34

n

-3 Circuit

Isolated Resistors

-5 Circuit

Dual Terminator

12

34

R1

R2

n

12

34

n

-1 Circuit

Bussed Resistors

#ofLeads

4

5

6

7

8

9

10

11

12

13

14

Dim.“L”

Max.

.40

10.16

.50

12.70

.60

15.24

.70

17.78

.80

20.32

.90

22.86

1.00

25.40

1.10

27.94

1.20

30.48

1.30

33.02

1.40

35.56

.200

.098

5.08

2.5

SIL Resistor Network

L Series

Make Possible

10.14

General Note

TT Electronics reserves the right to make changes in product specification without notice or liability.

All information is subject to TT Electronics’ own data and is considered accurate at time of going to print.
