OUTLINE DIMENSIONS

0.50

BSC

BOTTOM VIEW

TOP VIEW

PIN 1

INDICATOR

PIN 1

INDICATOR

SEATING

PLANE

0.05 MAX

0.02 NOM

0.203 REF

COPLANARITY

0.08

0.30

0.25

0.18

6.10

6.00 SQ

5.90

0.80

0.75

0.70

FOR PROPER CONNECTION OF

THE EXPOSED PAD, REFER TO

THE PIN CONFIGURATION AND

FUNCTION DESCRIPTIONS

SECTION OF THIS DATA SHEET.

0.45

0.40

0.35

0.20 MIN

4.70

4.60 SQ

4.50

COMPLIANT TO JEDEC STANDARDS MO-220-WJJD-5

END VIEW

EXPOSED

PAD

Figure 59. 40-Lead Lead Frame Chip Scale Package [LFCSP]

6mm × 6mm Body and 0.75 mm Package Height

(CP-40-7)

Dimensions shown in millimeters

ORDERING GUIDE

Model1

Temperature Range

Package Description

Package Option

ADRF6820ACPZ-R7

−40°C to +85°C

40-Lead Lead Frame Chip Scale Package [LFCSP]

CP-40-7

ADRF6820-EVALZ

Evaluation Board

Z = RoHS Compliant Part.
