ADA4530-1

Data Sheet

Rev. A | Page 24 of 50

0.1

0.001

0.01

100

10k

100k

FREQUENCY (Hz)

90kHz LOW-PASS FILTER

500kHz LOW-PASS FILTER

VSY = 4.5V

AV = +1

RL = 10kΩ

VIN = 0.5V rms

Figure 79. THD + N vs. Frequency, VSY = 4.5 V

0.1

0.001

0.01

100

10k

100k

FREQUENCY (Hz)

90kHz LOW-PASS FILTER

500kHz LOW-PASS FILTER

VSY = 10V

AV = +1

RL = 10kΩ

VIN = 2V rms

Figure 80. THD + N vs. Frequency, VSY = 10 V

0.1

0.001

0.01

100

10k

100k

FREQUENCY (Hz)

90kHz LOW-PASS FILTER

500kHz LOW-PASS FILTER

VSY = 16V

AV = +1

RL = 10kΩ

VIN = 4.5V rms

Figure 81. THD + N vs. Frequency, VSY = 16 V

0.1

0.001

0.01

0.001

0.01

0.1

AMPLITUDE (V rms)

90kHz LOW-PASS FILTER

500kHz LOW-PASS FILTER

VSY = 4.5V

AV = +1

RL = 10kΩ

f = 1kHz

Figure 82. THD + N vs. Amplitude, VSY = 4.5 V

0.1

0.0001

0.001

0.01

0.001

0.01

0.1

AMPLITUDE (V rms)

90kHz LOW-PASS FILTER

500kHz LOW-PASS FILTER

VSY = 10V

AV = +1

RL = 10kΩ

f = 1kHz

Figure 83. THD + N vs. Amplitude, VSY = 10 V

0.1

0.001

0.01

0.001

0.01

0.1

AMPLITUDE (V rms)

90kHz LOW-PASS FILTER

500kHz LOW-PASS FILTER

VSY = 16V

AV = +1

RL = 10kΩ

f = 1kHz

Figure 84. THD + N vs. Amplitude, VSY = 16 V
