Data Sheet

ADA4530-1

Rev. A | Page 9 of 50

ABSOLUTE MAXIMUM RATINGS

Table 4.

Parameter

Rating

Supply Voltage

17 V

Input Voltage

(V−) − 0.3 V to (V+) + 0.3 V

Input Current1

10 mA

Differential Input Voltage

±0.7 V

Output Short-Circuit Duration to GND

Indefinite

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +125°C

Junction Temperature Range

−65°C to +150°C

Lead Temperature (Soldering, 60 sec)

300°C

ESD

Human Body Model2

4 kV

Field Induced Charged Device

Model (FICDM)3

1.25 kV

1 The input pins have clamp diodes to the power supply pins. Limit the input

current to 10 mA or less whenever input signals exceed the power supply

rail by 0.3 V.

2 Applicable Standard ESDA/JEDEC JS-001-2012.

3 Applicable Standard JESD22-C101-E (ESD FICDM standard of JEDEC).

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

θJA is specified for the worst case conditions, that is, a device

soldered in a circuit board for surface-mount packages using a

standard 4-layer JEDEC board.

Table 5. Thermal Resistance

Package Type

θJA

θJC

Unit

8-Lead SOIC

122

°C/W

ESD CAUTION
