background image
INCHANGE Semiconductor
isc website：www.iscsemi.com
isc & iscsemi is registered trademark
2
isc Silicon NPN Power Transistors
2SD583
ELECTRICAL CHARACTERISTICS
Tj=25℃ unless otherwise specified
SYMBOL
PARAMETER
CONDITIONS
MIN
MAX
UNIT
VCEO(SUS)
Collector-Emitter Sustaining Voltage
IC= 50mA ;IB= 0
250
V
VCE(sat)-1
Collector-Emitter Saturation Voltage
IC= 8A; IB= 0.8A
1.4
V
VCE(sat)-2
Collector-Emitter Saturation Voltage
IC= 15A; IB= 3A
4.0
V
VBE(on)
Base-Emitter On Voltage
IC= 8A ; VCE= 4V
2.2
V
ICEO
Collector Cutoff Current
VCE= 250V; IB= 0
0.5
mA
ICBO
Collector Cutoff Current
VCB= 250V; IE= 0
0.1
mA
IEBO
Emitter Cutoff Current
VEB= 5V; IC=0
0.1
mA
hFE-1
DC Current Gain
IC= 2A ; VCE= 5V
60
200
hFE-2
DC Current Gain
IC= 8A ; VCE= 5V
30
fT
Current-Gain—Bandwidth Product
IC= 1A ; VCE= 10V; ftest= 1.0MHz
4
MHz
