TMS320C31, TMS320LC31
DIGITAL SIGNAL PROCESSORS
SPRS035B – MARCH 1996 – REVISED JANUARY 1999
47
POST OFFICE BOX 1443
• HOUSTON, TEXAS 77251–1443
MECHANICAL DATA
PQ (S-PQFP-G***)
PLASTIC QUAD FLATPACK
100 LEAD SHOWN
88
0.012 (0,30)
0.008 (0,20)
64
0.025 (0,635)
Seating Plane
132
1.090 (27,69)
1.070 (27,18)
0.966 (24,54)
0.934 (23,72)
1.112 (28,25)
1.088 (27,64)
0.800 (20,32)
4040045 / C 11/95
100
1
13
63
39
”D2” SQ
”D1” SQ
”D” SQ
14
”D3” SQ
38
DIM
”D”
”D2”
”D3”
”D1”
NOM
MIN
MAX
MIN
MAX
MIN
MAX
LEADS ***
0.180 (4,57) MAX
100
0.890 (22,61)
0.870 (22,10)
0.766 (19,46)
0.734 (18,64)
0.912 (23,16)
0.888 (22,56)
0.600 (15,24)
0.004 (0,10)
M
0.006 (0,15)
0.010 (0,25)
0.020 (0,51) MIN
0.130 (3,30)
0.150 (3,81)
0.006 (0,16) NOM
Gage Plane
0.036 (0,91)
0.046 (1,17)
0
°–8°
89
NOTES: A. All linear dimensions are in inches (millimeters).
B. This drawing is subject to change without notice.
C. Falls within JEDEC MO-069
