U74LVC1G02

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

5 of 5

www.unisonic.com.tw

QW-R502-400.E



TEST CIRCUIT AND WAVEFORMS

Note: CL includes probe and jig capacitance.

All input pulses are supplied by generators having the following characteristics: PRR ≤10MHz, ZO = 50Ω.

UTC assumes no responsibility for equipment failures that result from using products at values that

exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or

other parameters) listed in products specifications of any and all UTC products described or contained

herein. UTC products are not designed for use in life support appliances, devices or systems where

malfunction of these products can be reasonably expected to result in personal injury. Reproduction in

whole or in part is prohibited without the prior written consent of the copyright owner. The information

presented in this document does not form part of any quotation or contract, is believed to be accurate

and reliable and may be changed without notice.

Inputs

VCC

VIN

tR, tF

1.8V±0.15V

VCC

≤2ns

VCC/2

15pF

1MΩ

2.5V±0.2V

VCC

≤2ns

VCC/2

15pF

1MΩ

3.3V±0.3V

≤2.5ns

1.5V

15pF

1MΩ

5V±0.5V

VCC

≤2.5ns

VCC/2

15pF

1MΩ

1.8V±0.15V

VCC

≤2ns

VCC/2

30pF

1KΩ

2.5V±0.2V

VCC

≤2ns

VCC/2

30pF

500Ω

3.3V±0.3V

≤2.5ns

1.5V

50pF

500Ω

5V±0.5V

VCC

≤2.5ns

VCC/2

50pF

500Ω
