Low-Power, Multifunction, Polyphase AFE

with Harmonics and Tamper Detect

______________________________________________________________________________________

Timeouts

Communications Timeout (COM_TIMO) (0x056)

This register specifies the duration of SPI timeout in ADC frames (default 360μs).

Energy Accumulation Timeout (ACC_TIMO) (0x058)

This register specifies the time in DSP cycles that the MAXQ3183 waits before accumulating energy. If this register is

nonzero, it is decremented on each DSP cycle. If the result of the decrement is nonzero, the results of the DSP cycle

are discarded and are not accumulated to the energy registers. This register is useful for delaying the initiation of

energy accumulation on startup or after some hardware function has been modified.

Bit:

Name:

Communications Timeout High Byte

Reset:

0x03

Bit:

Name:

Communications Timeout Low Byte

Reset:

0xE8

Bit:

Name:

Energy Accumulation Timeout High Byte

Reset:

0x00

Bit:

Name:

Energy Accumulation Timeout Low Byte

Reset:

0x05
