background image
AD8432
Rev. 0 | Page 12 of 28
100ns/DIV
Figure 33. Overdrive Recovery, G = 24.08 dB
10ns/DIV
G = 12.04dB
G = 18.06dB
G = 21.58dB
G = 24.08dB
Figure 34. Small Signal Transient Response vs. Gain, VIN = 100 mV p-p
10ns/DIV
Figure 35. Small Signal Transient Response, G = 12.04 dB
10ns/DIV
CL = 15pF
CL = 10pF
CL = 5pF
Figure 36. Small Signal Transient Response vs. Capacitive Load (CL), G = 12.04 dB
10ns/DIV
CL = 5pF
CL = 10pF
CL = 15pF
CL = 20pF
CL = 30pF
Figure 37. Small Signal Transient Response vs. Capacitive Load (CL), G = 24.08 dB
10ns/DIV
RL = 499Ω
RL = 249Ω
RL = 24.9Ω
RL = 15Ω
RL = 10Ω
Figure 38. Small Signal Transient Response vs. Resistive Load (RL), G = 12.04 dB
