AD8295
Rev. 0 | Page 13 of
28
2µV/DIV
1s/DIV
Figure 27. 0.1 Hz to 10 Hz RTI Voltage Noise, G = 1
0.1µV/DIV
1s/DIV
Figure 28. 0.1 Hz to 10 Hz RTI Voltage Noise, G = 1000
1
10
100
1k
10k
100k
FREQUENCY (Hz)
1k
100
10
Figure 29. Current Noise Spectral Density vs. Frequency
5pA/DIV
1s/DIV
Figure 30. 0.1 Hz to 10 Hz Current Noise
1k
10k
100k
1M
FREQUENCY (Hz)
30
25
20
15
10
5
0
GAIN = 1
GAIN = 10, 100, 1000
Figure 31. Large Signal Frequency Response
5V/DIV
0.002%/DIV
20µs/DIV
7.4µs TO 0.01%
8.3µs TO 0.001%
Figure 32. Large Signal Pulse Response and Settling Time, G = 1
