ST486DX - SMM SOFTWARE CONSIDERATIONS

3.3

Maintaining the CPU State

The following registers are not automatically saved/restored on SMM entry/exit.

General Purpose Registers:

EAX, EBX, ECX, EDX

Pointer and Index Registers:

EBP, ESI, EDI, ESP

Selector/Segment Registers:

DS, ES, SS, FS, GS

Descriptor Table Registers:

GDTR, IDTR, LDTR, TR

Control Registers:

CR2, CR3

Debug Registers:

DR0, DR1, DR2, DR3, DR6

Configuration Registers:

CCR1, CCR2, CCR3, SMAR

FPU Registers:

Entire FPU state.

If any of these registers need to be used by the SMM routine, the registers need to be saved after en-

try to the SMM routine and then restored prior to exit from SMM. Additionally, if power is to be

removed from the CPU and the system is required to return to the same system state after power is

reapplied, then the entire CPU state must be saved to a non-volatile memory subsystem such as a

hard disk.

3.3.1

Maintaining Common CPU Registers

The following is an example of the instructions needed to save the entire CPU state and restore it.

This code sequence will work from real mode if the conditions needed to execute SGS-Thomson

SMM instructions are met (see Section 2.3).

; Save and Restore the common CPU registers.

; The information automatically saved in the

; header on entry to SMM is not saved again.

include SMIMAC.INC

.386P

;required for SMIMAC.INC macro

mov

cs:save_eax,eax

mov

cs:save_ebx,ebx

mov

cs:save_ecx,ecx

mov

cs:save_edx,edx

mov

cs:save_esi,esi

mov

cs:save_edi,edi

mov

cs:save_ebp,ebp

mov

cs:save_esp,esp

svdc

cs:,save_ds,ds

svdc

cs:,save_es,es

svdc

cs:,save_fs,fs

svdc

cs:,save_gs,gs

svdc

cs:,save_ss,ss

svldt

cs:,save_ldt

;sldt is not valid in real mode
