Use the attached saddle to secure the end cap of the Protective Spi-

ral Tube. To secure the Protective Spiral Tube at a position other

than the end cap, apply tape to the tube so that the portion becomes

thicker in diameter.

End cap

WARNING

The E3X-NH/NHB is not a safety component for ensuring the

safety of people as defined in EC Directive 91/368/EEC, or as

covered by separate European standards or by any other reg-

ulations or standards.

Reflector

Observe the Following Precautions when Using the Reflec-

tor (E39-R3)

Use detergent, etc., to remove any dust or oil from the surfaces

where tape is applied. Adhesive tape will not be attached properly if

oil or dust remains on the surface.

The E39-R3 cannot be used in places where it is exposed to oil or

chemicals.

ALL DIMENSIONS SHOWN ARE IN MILLIMETERS.

To convert millimeters into inches, multiply by 0.03937. To convert grams into ounces, multiply by 0.03527.

Cat. No. E258-E1-3

In the interest of product improvement, specifications are subject to change without notice.

Printed in Japan

0698-1.5M (0297) a

OMRON Corporation

Industrial Sensors Division

Sensing Devices and Components Division H.Q.

28th Fl., Crystal Tower Bldg.

1-2-27, Shiromi, Chuo-ku,

Osaka 540-6028 Japan

Phone: (81)6-949-6012 Fax: (81)6-949-6021
