DOMINANT Semiconductors

19/05/05

S SpiceLED AlInGaP SSx-CLD-v3

Page 1 of 1

Surface Mount AlInGaP Spice LED : SSx-CLD

Note: The center pad is a common cathode. Please

take care during soldering to avoid shorting.

• High brightness diffused surface mount LED.

• Super wide viewing angle of 160°.

• Equivalent to 0603 package outline. Copper lead-frame construction.

• Qualified according to JEDEC moisture sensitivity Level 2.

• Compatible to IR reflow soldering.
