7 / 11 page

Nexperia

PUSB3AB2DF

Extremely low clamping low capacitance ESD protection

11. Package outline

References

Outline

version

European

projection

Issue date

IEC

JEDEC

JEITA

SOT8013

- - -

sot8013_po

19-08-06

19-08-29

Unit(1)

max

nom

min

0.275 0.03

0.350 0.650

0.12

0.03 0.05

Dimensions (mm are the original dimensions)

Note

1. Device is electrically symmetrical

DFN0603-3; plastic, ultra small and leadless full encapsulated package;

3 terminals; 0.225 mm pitch; 0.63 mm x 0.33 mm x 0.25 mm body

SOT8013

0.27

0.04

0.225

0.305 0.605

0.08

0.23

scale

0.5 mm

seating plane

(3x)

Fig. 11. Package outline DFN0603-3 (SOT8013)

PUSB3AB2DF

All information provided in this document is subject to legal disclaimers.

Product data sheet

22 November 2019

7 / 11
