B7A
B7A
3
10-point Terminal Models
Note:
The 10-point model has a normal I/O delay time of 19.2 m (typical); 10-point models with short I/O delay time are not available.
The transmission signals of the 16-point PLC connector model are not compatible with those of the 10-point model. Therefore
16-point PLC connector models and 10-point models cannot be used in combination.
B7A
B7A
B7AC
B7A
B7A
FA connector model (10 points)
Modular model (10 points)
Modular model (10 points)
Screw terminal model (10 points)
Screw terminal model (10 points)
Input (Transmission)
Output (Reception)
DRT1-B7AC
DeviceNet model
