www.ti.com
EXAMPLE STENCIL DESIGN
12X (0.92)
12X (0.97)
(0.585)
TYP
(0.56) TYP
42X (0.6)
42X (0.25)
38X (0.5)
(3.3)
(8.8)
(R0.05) TYP
WQFN - 0.8 mm max height
RUA0042A
PLASTIC QUAD FLATPACK - NO LEAD
4219139/A 03/2020
NOTES: (continued)
6. Laser cutting apertures with trapezoidal walls and rounded corners may offer better paste release. IPC-7525 may have alternate
design recommendations.
SOLDER PASTE EXAMPLE
BASED ON 0.125 MM THICK STENCIL
SCALE: 12X
EXPOSED PAD 43
69% PRINTED SOLDER COVERAGE BY AREA UNDER PACKAGE
SYMM
SYMM
1
17
18
21
22
38
39
42
43
