6 / 16 page ![]() ADL5530 Data Sheet Rev. C | Page 6 of 16 PIN CONFIGURATION AND FUNCTION DESCRIPTIONS NC IN1 NC NC GND OUT1 NC NC NOTES 1. NC = NO CONNECT. 2. THE EXPOSED PADDLE IS INTERNALLY CONNECTED TO GND. SOLDER TO A LOW IMPEDANCE GROUND PLANE. 1 2 3 4 8 7 6 5 ADL5530 TOP VIEW (Not to Scale) Figure 2. Pin Configuration Table 4. Pin Function Descriptions Pin No. Mnemonic Description 1, 3, 4, 5, 6 NC No Connect. 2 IN1 RF Input. Requires a DC blocking capacitor. 7 OUT1/ VPOS RF Output and VPOS (Supply Voltage). DC bias is provided to this pin through an inductor. RF path requires a DC blocking capacitor. 8 GND Ground. Connect this pin to a low impedance ground plane. Exposed Paddle Internally connected to GND. Solder to a low impedance ground plane. |
|
|
