Mid-IR – Product Line Overview

1 of 2

Mid-IR Products

Product Line Overview

Mid-Infrared Light Emitting Diodes and Photodiodes

We offer:

• Standard LEDs

• Flip-Chip bounded LEDs

• Multi Chip LEDs

• PDs

• LED drivers and PD amplifiers

Standard LEDs

LED chips with circular or ring top contact

Product series

Peak wavelength

Product series

Peak wavelength

LED18

1.85 – 1.88 µm

LED35

3.55 µm

LED19

1.95 µm

LED36

3.65 µm

LED20

2.05 µm

LED38

3.75 µm

LED21

2.15 – 2.18 µm

LED39

3.90 µm

LED22

2.20 – 2.27 µm

LED41

4.05 µm

LED23

2.31 – 2.35 µm

LED43

4.15 µm

LED29

2.84 µm

LED46

4.45 µm

LED34

3.40 µm

Flip-Chip bounded LEDs

LED chip top surface is free of contacts

Product series

Peak wavelength

Product series

Peak wavelength

LED16FC

1.65 µm

LED21FC

2.15 µm

LED17FC

1.75 µm

LED22FC

2.25 µm

LED18FC

1.85 µm

LED23FC

2.35 µm

LED19FC

1.95 µm

LED34FC

3.40 µm

LED20FC

2.05 µm

LED37FC

3.75 µm

Multi Chip LEDs

A number of similar or different LED-chips mounted in a single compact package and driven

together or independently.

Flip-Chip bounded LEDs

LED chip top surface is free of contacts

Product series

Peak wavelength

Product series

Peak wavelength

LED16FC

1.65 µm

LED21FC

2.15 µm

LED17FC

1.75 µm

LED22FC

2.25 µm
