Designed for Rugged Excellence

▪

Open-Ring : Open-Ring is an enhanced redundant technology that makes ORing's switches compatible with other vendor's proprietary redundant

ring technologies. It enables ORing's switches to form a single ring with other vendor's switch. In cases where the ring is setup using proprietary

technology, ORing offers a compatibility service where ORing can make its switches compatible with your particular network requirements.

▪

O-Chain : O-Chain is the revolutionary network redundancy technology that provides the add-on network redundancy topology for any backbone

network, O-Chain allows multiple redundant network rings of different redundancy protocols to join and function together as a larger and more

robust compound network topology. O-Chain providing ease-of-use while maximizing fault-recovery swiftness, flexibility, compatibility, and cost-

effectiveness in one set of network redundancy topology.

▪

overcome any single failure with recovery time much faster than achievable with Spanning Tree Protocol.

▪

IP-based Bandwidth Management : The switch provide advanced IP-based bandwidth management which can limit the maximum bandwidth

for each IP device. User can configure IP camera and NVR with more bandwidth and limit other device bandwidth.

▪

Application-Based QoS : The switch also support application-based QoS. Application-based QoS can set highest priority for data stream according

to TCP/UDP port number.

▪

Device Binding Function : ORing special Device Binding function can only permit allowed IP address with MAC address to access the network.

Hacker cannot access the IP surveillance network without permission. It can avoid hacker from stealing video privacy data and attacking IP camera,

NVR and controllers.

▪

Advanced DOS/DDOS Auto Prevention : The switch also provided advanced DOS/DDOS auto prevention. If there is any IP flow become big in

short time, the switch will lock the source IP address for certain time to prevent the attack. It's hardware based prevention so it can prevent DOS/DDOS

attack immediately and completely.

▪

IEEE 1588v2 Technology : The IEEE 1588v2 technology can fulfill precision time synchronization requirements for protection and control

applications.

▪

Modbus TCP : This is a Modbus variant used for communications over TCP/IP networks.

▪

IEEE 802.3az Energy-Efficient Ethernet : This is a set of enhancements to the twisted-pair and backplane Ethernet family of networking

standards that will allow for less power consumption during periods of low data activity. The intention was to reduce power consumption by 50% or

more.

v1.0a / Feb, 2013

Industrial Ethernet Switch DIN-Rail Managed Gigabit PoE Ethernet Switch

Dimensions

(Unit=mm)

Dimension (Unit =mm)

*NOTE: This function is available by request only
