Typical Performance Characteristics (Continued)
RL
10 kX TA
25 C unless otherwise noted
Differential Gain
(Note)
TLH11061 4
Differential Phase
(Note)
TLH11061 5
Note
Differential gain and differential phase
measured for four series LM6362 op amps con-
figured with gain of a2 each in series with a
116 attenuator and an LM6321 buffer Error
added by LM6321 is negligible Test performed
using Tektronix Type 520 NTSC test system
Step Response Av
a
2
TLH11061 6
TIME (50 nsdiv)
Input Noise Voltage
Input Noise Current
Power Bandwidth
TLH11061 7
