Copyright © 2014 Future Technology Devices International Limited
12
Document No.: FT_000646
FT120 USB DEVICE CONTROLLER WITH PARALLEL BUS IC
Datasheet Version 1.2
Clearance No.: FTDI#
291
The EP2 buffer also supports DMA operation. The MCU needs to initialize the DMA operation through the
Set DMA command. Once DMA operation is enabled, data will be moving between the system memory
and FT120 endpoint buffer under the DMA controller. Buffer switching between ping buffer and pong
buffer is handled automatically.
