background image
INCHANGE Semiconductor
isc website：www.iscsemi.cn
isc & iscsemi is registered trademark
1
isc Silicon NPN RF Transistor
2SC4591
DESCRIPTION
·
High Current-Gain Bandwidth Product
fT= 9.0GHz TYP. @VCE = 5 V, IC = 20 mA
·
Low Noise
NF = 1.2 dB TYP. @VCE = 5 V, IC = 5 mA, f = 900 MHz
·
High Power Gain
PG = 12.5 dB TYP. @VCE = 5 V, IC = 20 mA, f = 900 MHz
·
100% avalanche tested
·
Minimum Lot-to-Lot variations for robust device
performance and reliable operation
APPLICATIONS
·
Designed for VHF, UHF low noise amplifier.
ABSOLUTE MAXIMUM RATINGS(Ta=25℃)
SYMBOL
PARAMETER
VALUE
UNIT
VCBO
Collector-Base Voltage
15
V
VCEO
Collector-Emitter Voltage
9
V
VEBO
Emitter-Base Voltage
1.5
V
IC
Collector Current-Continuous
50
mA
PC
Collector Power Dissipation
@TC=25℃
0.15
W
TJ
Junction Temperature
150
℃
Tstg
Storage Temperature Range
-55~150
℃
