October 2015

DocID027352 Rev 4

1/18

This is information on a product in full production.

www.st.com

STGP10M65DF2

Trench gate field-stop IGBT, M series 650 V, 10 A low loss

Datasheet - production data

Figure 1: Internal schematic diagram

Features



6 µs of short-circuit withstand time



VCE(sat) = 1.55 V (typ.) @ IC = 10 A



Tight parameter distribution



Safer paralleling



Low thermal resistance



Soft and very fast recovery antiparallel diode

Applications



Motor control



UPS



PFC

Description

This device is an IGBT developed using an

advanced proprietary trench gate field-stop

structure. The device is part of the M series of

IGBTs, which represents an optimum

compromise in performance to maximize the

efficiency of inverter systems where low loss and

short-circuit capability are essential. Furthermore,

a positive VCE(sat) temperature coefficient and tight

parameter distribution result in safer paralleling

operation.

Table 1: Device summary

Order code

Marking

Package

Packing

STGP10M65DF2

G10M65DF2

TO-220

Tube
