LMV331-N, LMV339-N, LMV393-N
www.ti.com
SNOS018H – AUGUST 1999 – REVISED DECEMBER 2014
Application Information (continued)
Figure 14. ORing the Outputs
8.1.4 Driving CMOS and TTL
The output of the comparator is capable of driving CMOS and TTL Logic circuits. The pull-up resistor may be
pulled-up to any voltage equal to, or less than the supply voltage on V+. However, it must not be pulled-up to a
voltage higher than V+.
Figure 15. Driving CMOS
Copyright © 1999–2014, Texas Instruments Incorporated
Submit Documentation Feedback
13
Product Folder Links: LMV331-N LMV339-N LMV393-N
