UNISONIC TECHNOLOGIES CO., LTD

2N65L

Power MOSFET

www.unisonic.com.tw

1 of 7

QW-R502-580.E

2A, 650V N-CHANNEL

POWER MOSFET



DESCRIPTION

The UTC 2N65L is a high voltage power MOSFET and is

designed to have better characteristics, such as fast switching

time, low gate charge, low on-state resistance and a high

rugged avalanche characteristics. This power MOSFET is

usually used in the high speed switching applications of power

supplies, PWM motor controls, high efficient DC to DC

converters and bridge circuits.



FEATURES

* RDS(ON) < 5.0Ω @ VGS = 10V, ID =1A

* Ultra Low gate charge (typical 9.0nC)

* Low reverse transfer capacitance (CRSS = typical 5.0 pF)

* Fast switching capability

* Avalanche energy specified

* Improved dv/dt capability, high ruggedness



SYMBOL
