UT06P03
Power MOSFET
UNISONICTECHNOLOGIESCO.,LTD
2 of 6
www.unisonic.com.tw
QW-R502-156.D
ABSOLUTE MAXIMUM RATINGS (TC = 25°C, unless otherwise specified)
PARAMETER
SYMBOL
RATINGS
UNIT
Drain-Source Voltage
VDSS
-30
V
Gate-Source Voltage
VGSS
±20
V
Continuous Drain Current
ID
-4
A
Pulsed Drain Current (Note 1, 2)
IDM
-20
A
Total Power Dissipation (TA = 25°C)
SOT-89
PD
0.78
W
SOT-26
0.41
W
TO-252
1
W
Junction Temperature
TJ
+150
°C
Storage Temperature
TSTG
-55 ~ +150
°C
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
THERMAL DATA
PARAMETER
SYMBOL
MAX
UNIT
Junction to Ambient
SOT-89
θJA
160
°C/W
SOT-26
300
°C/W
TO-252
110
°C/W
Junction to Case
SOT-89
θJC
18
°C/W
SOT-26
110
°C/W
TO-252
7.93
°C/W
